Application

1.Treat various of unqualified insulation oils including aging transformer oil esp. for the power which is above 110KV, mutual inductor oil, switch oil and so on.

2.Inject the insulating oil into the transformers on-line automatically.

Features
1.The device adopts auto-control by central data processing, and processes kinds of variable feedback data immediately, then sets instructions.

2.Advanced infrared liquid-level control system to accomplish fully automatic control.
3.High vacuum: High point-Vacuum≤5pa Working-vacuum≤35pa
4.High absorption speed: Absorption speed power≥333L/Sr.
5.Duplex 3D stereo-evaporation to eliminate the liquid water quickly
6.UK G technology to remove the trace water that is show chain like dissolved water effectively.
7.Filter through double FH trapezoidal network and absorb by high polymer without the mechanical power to distinctively remove impurities.

8.Carbon fiber infrared heating system to make the oil contains zero sum of ethyne after the treatment.

9.Esp. applied to vacuum oiling and drying for power transmission equipments which are over 110KV
10.The oil of any grades can be treated on line at the working site
Advantages
1.Fully automatic 24 hour continuous operation, enables unattended supervision
2.Dewater, degas and remove the impurities more quickly, more completely, making the limiting voltage-withstand value of oil much higher.

3.The bridge-type vacuum linking system can purify and be an independent vacuum power supply to treat the electric insulation devices.

4.All necessary control switch, light indicator and meter are equipped on the control panel which provides easy control for operation and supervision.
